Rubber Hose

Rubber Hose
Rubber Hose
Product Code : 589-VV02
Product Description

589    VV02             Rubber Hose



BD

FG

BLU-WHT

TPS

0

0

0

FLX

0

HT

0

SW

0

0

0

0

0

0

0

4.5-8.0





Colour:

blue with white longitudinal stripe; white liner





Temperature range:

-30 °C +100 °C



Technical features:

highly hygienic flexible hose made from TPS elastomeric with built-in steel spiral and polyester reinforcement. Inside and outside completely smooth to facilitate the flow of the medium and the cleaning and sterilization process before and after use. Manufactured with stricter tolerances when compared  with  equivalent  rubber  hoses.  Extremely  lightweight  and  flexible,  it  makes  manual operations in-plant and on unloading platforms easier.



Tube features:

the extruded, low porosity TPS tube reduces permeation problems. Highly neutral in taste and odor, it preserves the organoleptic properties of the medium. Good chemical resistance to acids and alkaline solutions and good impermeability. Versatile rubber resistant also to alcohol concentration of

50%.

Cover features:

excellent resistance to ozone, ageing, UV rays and weather conditions.

Curing-free material:

the production ofhose does not need any vulcanization process, therefore preventing the risk of leaching of curing agent residues into the end product (peroxide or platinum volatile rests). It also allows energy savings and limited CO2 emissions.



Application:

ideal solution to deliver milk, buttermilk, yogurt, cream and acid cream, fresh cheese

and other dairy products with low fat content. Suitable to deliver liquid foods in general with alcoholic concentration up to 50%.


TECHNICAL DATA:



Ø

inside

Ø

outside



Weight



WP



BP



Vacuum

Bending

r.

Coil

length



Volume

mm

mm

g/m

bar

bar

mH2O

mm

m

m3

20

29

380

10

30

10

60

60

0,105

25

35

530

10

30

10

100

60

0,135

32

43

710

10

30

9

130

60

0,214

38

49

820

10

30

9

150

30

0,228

50

63

1400

10

30

8

250

30

0,286

63

77

1820

10

30

8

320

30

0,372

76

91

2210

10

30

7

380

30

0,603

80

95

2290

10

30

7

400

20

0,498

102

118

3150

10

30

7

510

20

0,801
